12kw Green Energy Private Home Wind Turbine System , Roof Mounted Wind Turbine

Brand Name : HYE

Model Number : HY-3000

Certification : CE, ISO9001, RoHs

Place of Origin : Guangzhou,China

MOQ : 1pc

Price : Negotiable

Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000sets/month

Delivery Time : 3-5days

Packaging Details : standard export packing

Rated output : 3000w

Peak output : 3500w

Start up speed : 2m/s

Rated wind speed : 12m/s

Over speed control : electromagnetic and blade aerodynamic braking

Genrator type : brushless 3 phase PMA with high performance magnet

Net weight : 70kgs

Warranty : 3years

Contact Now

12kw Green Energy Home Wind Turbine System With 3 Years Warranty , Fit For Home Use

Brief introduction:

A typical stand-alone system consists of a small wind turbine and solar panels to generate electricity connected to a charge controller which controls the pace at which batteries are recharged which is connected the battery bank. You will then need an off-grid inverter to convert the DC electricity stored in the battery bank to AC electricity which is more commonly used in home & business appliances.

The benefit of wind solar hybrid off grid power system

Minimize Your Impact - Capturing the energy that is freely available in the wind and sun, you will be able reduce your impact on the environment - contributing to the health of our planet.
Take Control - Producing your own energy allows you to choose a clean, renewable energy source, allowing you to go green on your own terms.
Live off the grid - Our wind/solar hybrid solutions allow you to live off the grid and overcome unreliable energy sources. Keep the power on.
Save Money - With ever-rising electricity prices, it will be a relief to take charge and lower your utility bills.

12kw wind and solar hybrid system

Components	Model No.	Specification	Quantity
Wind turbine	HY-3000L	3000W wind turbine,5blades	2
Solar panel	HY-TLPV135	135W polysilicon solar modules	45
Controller inverter		6kw wind, 6kw solar, 5kw inverter output	1
Battery bank	200AH/12V	200AH/12V Gel battery	18
Guyed tower	9m	9m guyed tower for 3kw wind turbine	2
solar panel installation bracket		bracket for solar panel	45

Solar panel specification

	HY-TLPV135
Max-power:Pm(W)	135W
Max-power voltage: Vm(V)	17.8V
Max-power current: Im(A)	7.58A
Open-circuit voltage:Voc(V)	21.8V
Short-circuit current: Isc(A)	8.10A
Max-system voltage(VDC)	1000V
Operating temperature(℃)	-40~+85℃
Power tolerance(%)T	0~+6W
Type of solar cell	Polycrystalline
Lay up of solar cell	36(4*9)PCS
Dimension of solar module	148066530mm
Gross weight of solar module	11.2Kg
Front Cover	Low-iron Tempered glass/ 3.2mm
Frame	Anodization aluminum
Junction Box (protection degree)	IP65
Hailstone Impact	25mm at 23m/s

FAQ

Q: What is the difference between on-grid and off-grid turbines? How do I know which one is right for me?

A: If your home currently gets its energy from a utility company, you will need an on-grid turbine, which helps decrease your monthly utility bill by generating energy your home draws on before it turns to your utility company for energy. If you currently don't have the option of buying energy from a utility company, you have what is known as an off-grid need. Homeowners with off-grid needs often create what is known as a hybrid system, which employs both wind energy and energy generated by solar photovoltaic cells to keep their batteries charged.

Product Tags:

home wind turbine generator

residential rooftop wind turbine

12kw Green Energy Private Home Wind Turbine System , Roof Mounted Wind Turbine Images
