Light Weight 600W 24V Home Wind Turbine For Residential Area and Waterproof
Brief introduction
A typical stand-alone system consists of a small wind turbine and solar panels to generate electricity connected to a charge controller which controls the pace at which batteries are recharged which is connected to the battery bank. You will then need an off-grid inverter to convert the DC electricity stored in the battery bank to AC electricity which is more commonly used in home & business appliances.
Separately, wind and solar energy are effective ways to power a home or a business but can be limited due to lack of sun or a sudden shift in wind velocity. Using a combination of these will provide a stable, higher energy output to power your home or business. Wind solar hybrid power system includes a solar panel array and one or more wind turbines, and they create a more constant flow of power than either single source provided.
Wind & Solar hybrid power system provides a much more reliable power supply for 24 x 7 powers for off-grid applications. Off-grid systems can provide power anywhere; there is no shortage of possibilities or limits. Our packaged systems are ideally suited to remote homes, schools and other off-grid applications. They can also be retrofitted to existing diesel-generator systems to save on high fuel costs and minimize noise.
HY Energy offers standard hybrid systems solution with all necessary components such as solar panel, wind turbine, deep cycle battery, controller and inverter, mounting towers etc., each and every component has been well developed and tested for years in the fields and offers the highest levels of reliability, efficiency and ease of use, we can also custom design a system base on your project specific requirements.
HYE Wind Solar Hybrid Off-grid Power Systems Include
HY series small wind turbine 400W/600W/1000W/1500W/3000W
High Quality Solar Modules with 25 Years Warranty
wind solar hybrid charge controller and MPPT & charging boost function
600W - 6000W Pure Sine Wave Inverter 110V/220V/230V/240V
High Quality Deep Cycle Battery (100/150/200AH2/4/6/12V)
PV Mounting Frames (Roof top, ground mount, pole mount etc.)
Wind turbine towers (guyed tower, standing-free tower, hydraulic tower etc.
600w wind turbine specification
| Model |
HY-600 |
| Rated Output |
600W |
| Peak Output |
750W |
| Rated Voltage |
Grid-off DC24/48V or grid-tie DC48 V |
| Start-up Wind Speed |
2 m/s or 4.5mph |
| Cut-in Wind Speed |
2.5m/s or 5.6mph |
| Rated Wind speed |
12m/s or 26.8mph |
| Working Temp. range |
from -40°C to 60°C |
| Survival Max. wind |
50m/s or 110mph |
| Over speed control |
Electromagnetic & blade aerodynamic braking |
| Number of Blades |
5 |
| Rotor Diameter |
1.75m |
| Swept Area (m2) |
2.4㎡ |
| Blade Material |
Nylon fiberglass reinforced composite |
| Generator Type |
Brushless 3-phase PMA with high performance Neodymium Magnets |
| Tower-top Weight |
25kg |
| Tower Type |
self-supporting, guyed, Tilt-up tower or rooftop mounting etc. |
| Controller Type |
PWM |
| Applications |
solar & wind hybrid lighting, on/off-grid power system etc. |
| Product Life |
15 years |
| Warranty |
3 years (optional 5 years) |
| Years on Market |
7 years |
| Certificate |
CE, RoHS, ISO9001:2008, ISO14001 |
| Measurement |
125*52*25cm |
| Gross Weight |
28kgs |
